Zasilacz impulsowy przemysłowy nap. wej. 90÷264V AC/120÷370V DC, P=120W nap. Wyj. 12V DC
Information | Value |
---|---|
Supplier | F&F Filipowski Spółka Komandytowa |
Series | ZI |
Symbol | ZI-120-12V |
GTIN(EAN) | 5908312599487 |
Price unit | piece |
Catalog price | 467,40 zł (380,00 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Promotions related to this product
-
Promocja F&F - zegar astronomiczny
Za zakup asortymentu F&F na kwotę 2500 zł., zegar astronomiczny w cenie 3,69 zł.
-
Hager, Kontakt Simon, F&F - Razem na wiosnę - miksuj dowolnie
Kup produkty Hager, Kontakt Simon i F&F za kwotę 2000 zł netto i odbierz bezrękawnik
Description:
Typ zasilacz impulsowy Napięcie zasilania 100÷240 V AC Częstotliwość 50÷60 Hz Maksymalny prąd obciążenia 10 A Napięcie wyjściowe OUT 12 V DC Moc wyjściowa 120 W Minimalne obciążenie 0% Częstotliwość kluczowania 100 kHz Przeciążenie 150%/3 min Napięcie przebicia WE-WY 3 kV Masa 670 g Przyłącze zaciski śrubowe 4,0 mm² Moment dokręcający 0,5 Nm Temperatura pracy -10÷70°C Wymiary 130 mm x 67 mm x 115 mm Montaż na szynie 35 mm Stopień ochrony IP20
Additional features:
Information | Value |
---|---|
Gross weight: | 250 g |
ETIM class: | DC-power supply |
Voltage type (supply voltage): | AC |
Max. output current 1: | 10 A |
Secondary voltage adjustable: | yes |
Nominal value output voltage 1: | 12 V |
Rated supply voltage AC 50 Hz: | 100 - 240 V |
Output voltage stabilized: | yes |
Power consumption: | 2 VA |
Power output: | 120 W |
Stabilized: | yes |
Type of electric connection: | Screw connection |
Rail mounting possible: | yes |
Wall mounting possible: | no |
Modular version: | yes |
Width in number of modular spacings: | 4 |
Built-in width: | 67 mm |
Built-in height: | 130 mm |
Direct mounting possible: | no |
Width: | 67 mm |
Height: | 130 mm |
Depth: | 115 mm |
Degree of protection (IP): | IP20 |
