Falownik do silników jednofazowych, Pmax=1,5kW, Uwej=230V
| Information | Value |
|---|---|
| Supplier | F&F Filipowski Spółka Komandytowa |
| Series | FA |
| Symbol | FA-1F015 |
| GTIN(EAN) | 5908312590750 |
| Price unit | piece |
| Catalog price | 1 585,47 zł (1 289,00 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Promotions related to this product
Description:
Napięcie wejściowe 1 x 230 V Moc wejściowa 2,8 kVA Napięcie wyjściowe 1 x 230 V Prąd wyjściowy 10 A Maksymalna moc silnika 1,5 kW Liczba wejść cyfrowych 7 Wejścia - sterowanie bezpotencjałowe Liczba wejść analogowych 1 Wejścia analogowe - prądowe 1 Liczba wyjść analogowych 1 Wyjścia analogowe - prądowe 1 Wyjścia analogowe - napięciowe 1 Liczba wyjść przekaźnikowych 1 Liczba wyjść tranzystorowych 2 Długość L 112,5 mm Szerokość W 85 mm Wysokość H 141,5 mm Temperatura pracy -10÷40°C
Additional features:
| Information | Value |
|---|---|
| ETIM class: | Frequency converter =< 1 kV |
| Mains frequency: | 50 Hz |
| Number of phases input: | 1 |
| Number of phases output: | 1 |
| Max. output frequency: | 400 Hz |
| Nominal output current I2N: | 10 A |
| Max. output at quadratic load at rated output voltage: | 1.5 kW |
| Max. output at linear load at rated output voltage: | 1.5 kW |
| Relative symmetric net frequency tolerance: | 5 % |
| Relative symmetric net voltage tolerance: | 15 % |
| With control element: | yes |
| Application in industrial area permitted: | yes |
| Application in domestic- and commercial area permitted: | yes |
| Supporting protocol for TCP/IP: | no |
| Supporting protocol for PROFIBUS: | no |
| Supporting protocol for CAN: | no |
| Supporting protocol for INTERBUS: | no |
| Supporting protocol for ASI: | no |
| Supporting protocol for KNX: | no |
| Supporting protocol for Modbus: | yes |
| Supporting protocol for Data-Highway: | no |
| Supporting protocol for DeviceNet: | no |
| Supporting protocol for SUCONET: | no |
| Supporting protocol for LON: | no |
| Supporting protocol for PROFINET IO: | no |
| Supporting protocol for PROFINET CBA: | no |
| Supporting protocol for SERCOS: | no |
| Supporting protocol for Foundation Fieldbus: | no |
| Supporting protocol for EtherNet/IP: | no |
| Supporting protocol for AS-Interface Safety at Work: | no |
| Supporting protocol for DeviceNet Safety: | no |
| Supporting protocol for INTERBUS-Safety: | no |
| Supporting protocol for PROFIsafe: | no |
| Supporting protocol for SafetyBUS p: | no |
| Supporting protocol for other bus systems: | no |
| Number of HW-interfaces industrial Ethernet: | 0 |
| Number of interfaces PROFINET: | 0 |
| Number of HW-interfaces RS-232: | 0 |
| Number of HW-interfaces RS-422: | 0 |
| Number of HW-interfaces RS-485: | 1 |
| Number of HW-interfaces serial TTY: | 0 |
| Number of HW-interfaces USB: | 0 |
| Number of HW-interfaces parallel: | 0 |
| Number of HW-interfaces other: | 0 |
| With optical interface: | no |
| Integrated breaking resistance: | no |
| 4-quadrant operation possible: | no |
| Type of converter: | U converter |
| Degree of protection (IP): | IP20 |
| Height: | 141.5 mm |
| Width: | 85 mm |
| Depth: | 112.5 mm |
