Automat schodowy, do montażu podtynkowego
| Information | Value |
|---|---|
| Supplier | F&F Filipowski Spółka Komandytowa |
| Series | AS |
| Symbol | ASO-205 |
| GTIN(EAN) | 5908312596233 |
| Price unit | piece |
| Catalog price | 98,40 zł (80,00 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Promotions related to this product
Description:
Napięcie zasilania 230 V AC Maksymalny prąd obciążenia AC-1 10 A Element wykonawczy przekaźnik Konfiguracja styków 1 × NO Separacja styku NIE Opóźnienie zadziałania mniej niż 1 s Opóźnienie wyłączenia - regulowane 0,5 ÷ 10 min Przeciwblokada NIE Sygnalizacja wyłączenia NIE Współpraca z przyciskami podświetlanymi TAK Przyłącze 3×DY 1,0mm²; długość: 10cm Pobór mocy 0,4 W Temperatura pracy -25 ÷ 50 °C Wymiary Ø 55 mm; wysokość: 13 mm Montaż w puszce podtynkowej Ø60 Stopień ochrony IP20
Additional features:
| Information | Value |
|---|---|
| Gross weight: | 45 g |
| ETIM class: | Staircase lighting timer |
| Function: | Electronic |
| Mounting method: | Flush-mounted |
| Built-in depth: | 13 mm |
| Control voltage 1: | 230 - 230 V |
| Type of control voltage 1: | AC |
| Frequency control voltage 1: | 50 - 50 Hz |
| Type of control voltage 2: | AC/DC |
| Rated switch current: | 10 A |
| Release-delay: | 0.5 - 10 min |
| Wiring system: | 3 wire configuration |
| Pre-warning of switching-off: | Dimming up to 0 % |
| Repetitive: | Repetitive + continuous light |
| Supply voltage: | 230 - 230 V |
| Voltage type (supply voltage): | AC |
| Max. incandescent lamp load: | 1500 W |
| Max. load fluorescent lamp: | 350 VA |
| Max. load fluorescent lamp (Duo circuit): | 650 VA |
| Max. load fluorescent lamp (parallel compensated): | 500 VA |
