Automat schodowy, montaż na szynie DIN 42V
| Information | Value |
|---|---|
| Supplier | F&F Filipowski Spółka Komandytowa |
| Series | AS |
| Symbol | AS-B42 |
| GTIN(EAN) | 5908312590095 |
| Price unit | piece |
| Catalog price | 127,92 zł (104,00 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Promotions related to this product
Description:
Un=42V ; I=16A ; 2 moduły
Additional features:
| Information | Value |
|---|---|
| Gross weight: | 83 g |
| ETIM class: | Staircase lighting timer |
| Function: | Electronic with switching-off pre-warning |
| Mounting method: | DIN rail |
| Width in number of modular spacings: | 2 |
| Control voltage 1: | 42 - 42 V |
| Type of control voltage 1: | AC |
| Frequency control voltage 1: | 50 - 50 Hz |
| Type of control voltage 2: | AC/DC |
| Rated switch current: | 10 A |
| Release-delay: | 0.5 - 10 min |
| Wiring system: | 3 and 4 wire configuration |
| Pre-warning of switching-off: | Dimming up to 0 % |
| Repetitive: | Repetitive + continuous light |
| Supply voltage: | 230 - 230 V |
| Voltage type (supply voltage): | AC |
| Max. incandescent lamp load: | 1500 W |
| Max. load fluorescent lamp: | 350 VA |
| Max. load fluorescent lamp (Duo circuit): | 650 VA |
| Max. load fluorescent lamp (parallel compensated): | 500 VA |
