4-przewodowa listwa zaciskowa do zastosowań Ex e II 10-bieg., jasnoszara 264-240
Information | Value |
---|---|
Supplier | WAGO ELWAG Sp. z o.o. |
Symbol | 264-240 |
GTIN(EAN) | 4044918415743 |
Price unit | piece |
Catalog price | 83,22 zł (67,66 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Promotions related to this product
-
Wago. Kupuj w promocji. Oszczędzaj i odbieraj nagrody
Promocja skierowana wyłącznie dla Klientów spółki Karel 2 sp. z.o.o.
Dotyczy asortymentu firmy Wago - złączki listwowe i złączki instalacyjne (bez zestawów) -
Promocja WAGO
Za zakup asortymentu firmy WAGO, odbierz nagrodę: zestaw złączek instalacyjnych 887-802.
Description:
listwa zaciskowa 4-przewodowa; bez przycisków; do zastosowań Ex e II; z uchwytami montażowymi; 10-bieg.; do mocowania śrubowego i podobnego typu; otwór montażowy Ø 3,2 mm; 2,5 mm²; CAGE CLAMP®; 2,50 mm²; jasnoszary
Additional features:
Information | Value |
---|---|
Net weight: | 66 g |
ETIM class: | Single- and multi-pole terminal strip |
Operating temperature: | 105 - 105 °C |
Halogen free: | yes |
Explosion-tested version 'Ex e': | yes |
Rated current In: | 23 A |
Height: | 32 mm |
Closing plate required: | no |
Connectable conductor cross section fine-strand without cable end sleeve: | 0.5 - 2.5 mm² |
Type of electrical connection 1: | Spring clamp connection |
Type of electrical connection 2: | Spring clamp connection |
Connectable conductor cross section multi-wired: | 0.5 - 2.5 mm² |
Connectable conductor cross section solid-core: | 0.5 - 2.5 mm² |
Material insulation body: | Thermoplastic |
Connectable conductor cross section fine-strand with cable end sleeve: | 0.75 - 1.5 mm² |
Mounting method: | Other |
Colour: | Grey |
Width: | 116 mm |
Number of clamp positions per pole: | 4 |
Inflammability class of insulation material according to with UL94: | V0 |
Drill hole distance centrically: | 129.6 mm |
Rated voltage: | 690 V |
Number of poles: | 10 |
Depth: | 22.1 mm |
Transparent: | no |
