VG311F, zawór regulacyjny, 3-drogowy, DN100, kvs 130, przyłącze kołnierzowe, medium -10…150˚C, PN16
| Information | Value |
|---|---|
| Supplier | Schneider Electric Polska Sp. z o.o. |
| Symbol | VG311F-100C |
| GTIN(EAN) | 3606489646288 |
| Price unit | piece |
| Catalog price | 10 516,50 zł (8 550,00 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
Zawór kulowy VG311F to duży 3-drogowy zawór mieszający kulowy przeznaczony do szerokiej gamy zastosowań grzewczych i chłodniczych. Zawór jest wyposażony w koronkę, która zapewnia szeroki zakres nośników
Additional features:
| Information | Value |
|---|---|
| Gross weight: | 32 kg |
| ETIM class: | Three-way control valve |
| Flange compression class: | PN 16 |
| Surface protection: | Untreated |
| Characteristic curve: | Equal percentage |
| Leakage loss of Kvs value: | 0.03 % |
| Nominal diameter: | 4 inch (100) |
| Kvs value: | 100.00 |
| Article compression class: | PN 16 |
| Outer pipe diameter all connections: | 100 mm |
| Material quality: | Other |
| Connections: | Flange |
| Stroke length: | 45 mm |
| Max. medium temperature (continuous): | 150 °C |
| Housing material: | Cast iron |
| Min. medium temperature (continuous): | -10 °C |
