Stycznik mocy, TeSys Giga, 3 biegunowy (3NO), AC-3 <=440V 330A, wersja rozszerzona, 200…500V szerokozakresowa AC/DC cewka elektroniczna
| Information | Value |
|---|---|
| Supplier | Schneider Electric Polska Sp. z o.o. |
| Symbol | LC1G330LSEA |
| GTIN(EAN) | 3606481922472 |
| Price unit | piece |
| Catalog price | 9 041,18 zł (7 350,55 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Additional features:
| Information | Value |
|---|---|
| Gross weight: | 8,637 kg |
| ETIM class: | Power contactor, AC switching |
| Type of electrical connection of main circuit: | Bolt connection |
| Number of normally open contacts as main contact: | 3 |
| Number of normally closed contacts as main contact: | 0 |
| Number of auxiliary contacts as normally open contact: | 1 |
| Number of auxiliary contacts as normally closed contact: | 1 |
| Voltage type for actuating: | AC/DC |
| Rated operation current Ie at AC-3, 400 V: | 330.0 A |
| Rated operation current Ie at AC-1, 400 V: | 440.0 A |
| Rated operation power NEMA: | 250 kW |
| Rated control supply voltage AC 60 Hz: | 200 - 500 V |
| Rated control supply voltage AC 50 Hz: | 200 - 500 V |
| Rated control supply voltage DC: | 200 - 500 V |
| Rated operation power at AC-3, 400 V: | 160.0 kW |
| Modular version: | no |
| Rated operation power at AC-4, 400 V: | 160.0 kW |
| Rated operation current Ie at AC-4, 400 V: | 330 A |
Unfortunately, this product is not available in any warehouse of any wholesaler of the EL-Plus group. However, you can contact the wholesaler of your choice and order it.
Order
Wholesaler
Address
Distance
Actions
Szaflary,
ul. Zakopiańska 18
Distance:
Limanowa,
ul. Tarnowska 9D
Distance:
Gniezno,
ul. Słoneczna 40a
Distance:
Additional information:
| Information | Value |
|---|---|
| Updated: | 2024-09-23 00:04:45 |
| Files to download: | |
| External links: |
