Wyłącznik silnikowy, TeSys GV4, 3P, 25A, Icu 25kA, thermal magnetyczny, terminale EverLink
Information | Value |
---|---|
Supplier | Schneider Electric Polska Sp. z o.o. |
Symbol | GV4P25B |
GTIN(EAN) | 3606481310118 |
Price unit | piece |
Catalog price | 6 022,22 zł (4 896,11 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Additional features:
Information | Value |
---|---|
Gross weight: | 1,84 kg |
ETIM class: | Motor protection circuit-breaker |
Type of electrical connection of main circuit: | Screw connection |
Adjustment range undelayed short-circuit release: | 425 - 425 A |
Device construction: | Complete device in housing |
With integrated under voltage release: | no |
Number of poles: | 3 |
Degree of protection (IP): | IP40 |
Height: | 155 mm |
Rated operating voltage: | 690 - 690 V |
Depth: | 165 mm |
Width: | 81 mm |
Switch off technique: | Electronic |
Rated short-circuit breaking capacity lcu at 400 V, AC: | 25 kA |
Rated operation power at AC-3, 400 V: | 11 kW |
Phase failure sensitive: | yes |
With integrated auxiliary switch: | no |
Type of control element: | Turn button |
Rated permanent current Iu: | 25 A |
Overload release current setting: | 10 - 25 A |
With thermal overload protection: | yes |
Rated operation power at AC-3, 230 V: | 5.5 kW |
