PI6-1P-230VAC/DC (SZARE) (CE) Przekaźnik interfejsowy
| Information | Value |
|---|---|
| Supplier | RELPOL S.A. |
| Symbol | 858559 |
| Price unit | piece |
| Product withdrawn | This product is not produced any more. It might still be available if some wholesaler has it in it's stock |
| Sale price | from 59,16 zł / szt. (48,10 zł + 23 % VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
Przekaźnik interfejsowy wąskoprofilowy: 1P - jeden zestyk przełączny. Szerokość 6,2 mm. Zaciski śrubowe. Wyjście (niewymienne): styki 1P - zaciski: 11-12-14, AC1 - 6 A / 230 V; DC1 - 6 A / 24 V. Wejście - zaciski: (+)A1 - (-)A2, napięcie zasilania Un - 230 V AC/DC. Wymiary: 93,8 x 6,2 x 80 mm. Montaż na szynie 35 mm. IP 20.
Additional features:
| Information | Value |
|---|---|
| Net weight: | 40 g |
| ETIM class: | Switching relay |
| With detachable clamps: | no |
| Nominal current: | 6 A |
| Rated control supply voltage AC 50 Hz: | 0 - 0 V |
| Rated control supply voltage AC 60 Hz: | 0 - 0 V |
| Rated control supply voltage DC: | 230 - 230 V |
| Voltage type for actuating: | AC/DC |
| Drive, polarization: | Polarity free |
| Drive, switching attitude: | Mono stable |
| Number of contacts as normally closed contact: | 0 |
| Number of contacts as normally open contact: | 0 |
| Number of contacts as change-over contact: | 1 |
| With forced-guided contacts: | no |
| Type of switch contact: | Single contact |
| Complete with socket: | yes |
| With LED indication: | no |
| Material of contact surface: | Silver |
| Degree of protection (IP): | IP20 |
| Width: | 6.2 mm |
| Height: | 80 mm |
| Depth: | 93.8 mm |
buy at the outlet / on sale
Wholesaler / branch / Address
Distance
Available
Price
Actions
MEGA Tarnów
Tarnów, Towarowa 11
Tarnów, Towarowa 11
Distance:
1 sztuka
59,16 zł/szt.
Buy online
Buy / order
Wholesaler
Address
Distance
Available
Actions
Additional information:
| Information | Value |
|---|---|
| Updated: | 2024-06-07 15:39:07 |
| Files to download: |
