Przekaźnik czasowy 18-funkcyjny, LCD, styk: 1NO/NC, U=24-264V
| Information | Value |
|---|---|
| Supplier | F&F Filipowski Spółka Komandytowa |
| Series | PC |
| Symbol | PCS-517 |
| GTIN(EAN) | 5908312591627 |
| Price unit | piece |
| Catalog price | 354,24 zł (288,00 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Promotions related to this product
Description:
Napięcie zasilania 24÷264 V AC/DC Tryb pracy wielofunkcyjny Element wykonawczy przekaźnik Maksymalny prąd obciążenia 16 A Konfiguracja styków 1 × NO/NC Separacja styku TAK Opóźnienie zadziałania 500 ms Prąd impulsu sterującego mniej niż 1 mA Czas działania - regulowany 0,25sek÷99h59min59s Przyłącze zaciski śrubowe 4,0 mm² Moment dokręcający 0,5 Nm Pobór mocy 1,5 W Temperatura pracy -20÷50°C Wymiary 2 moduły (35 mm) Montaż na szynie 35 mm Stopień ochrony IP20
Additional features:
| Information | Value |
|---|---|
| Gross weight: | 77 g |
| ETIM class: | Timer relay for distribution board |
| Type of excitation: | Digital with multi function |
| Function: | Multi function |
| 1st interval unit: | Seconds/minutes |
| 2nd interval: | 9 - 264 |
| Mounting method: | DIN rail |
| Width in number of modular spacings: | 2 |
| Number of changeover switches: | 1 |
| Type of control voltage 1: | AC/DC |
| Supply voltage: | 24 - 264 V |
| Voltage type (supply voltage): | AC/DC |
| Nominal switching current at 250 V AC: | 16 A |
| Switch capacity incandescent lamps: | 2300 W |
| Switch capacity fluorescent lamp DUO: | 1000 VA |
| Switch capacity fluorescent lamp parallel: | 800 VA |
| Switch capacity fluorescent lamp inductive: | 1000 VA |
