WYŁĄCZNIK NADPRĄDOWY 6KA 1P C 10A
Information | Value |
---|---|
Supplier | BEMKO Sp. z o.o. |
Series | S7 |
Symbol | S-A00-S7-1P-C10 |
GTIN(EAN) | 5908311361474 |
Price unit | piece |
Catalog price | 17,47 zł (14,20 zł + 23% VAT) |
Sale price | from 5,28 zł / szt. (4,29 zł + 23 % VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Additional features:
Information | Value |
---|---|
Net weight: | 100 g |
Gross weight: | 100 g |
ETIM class: | Miniature circuit breaker (MCB) |
Built-in depth: | 50 mm |
Release characteristic: | C |
Number of poles (total): | 1 |
Number of protected poles: | 1 |
Rated current: | 10 A |
Rated voltage: | 230 V |
Rated insulation voltage Ui: | 300 V |
Rated impulse withstand voltage Uimp: | 4 kV |
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V: | 6 kA |
Voltage type: | AC |
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V: | 6 kA |
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V: | 6 kA |
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V: | 6 kA |
Frequency: | 50 - 60 Hz |
Current limiting class: | 1 |
Flush-mounted installation: | yes |
Concurrently switching neutral conductor: | no |
Over voltage category: | 3 |
Pollution degree: | 2 |
Additional equipment possible: | no |
Width in number of modular spacings: | 1 |
Degree of protection (IP): | IP20 |
Ambient temperature during operating: | -5 - 40 °C |
Connectable conductor cross section multi-wired: | 5 - 16 mm² |
Connectable conductor cross section solid-core: | 5 - 25 mm² |
