Moduł przekaźnikowy 24 V DC, szary 286-312/004-000
Information | Value |
---|---|
Supplier | WAGO ELWAG Sp. z o.o. |
Symbol | 286-312/004-000 |
GTIN(EAN) | 4055143105002 |
Price unit | piece |
Catalog price | 616,72 zł (501,40 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Promotions related to this product
Description:
przekaźnik; znamionowe napięcie wejściowe 24 V DC; 2 x zestyk przełączny; maksymalny prąd długotrwały 5 A; kolejnictwo; sygnalizacja statusu czerwony; szerokość 20 mm; szary
Additional features:
Information | Value |
---|---|
Net weight: | 39,8 g |
ETIM class: | Switching relay |
Height: | 70.2 mm |
Type of switch contact: | Single contact |
Complete with socket: | no |
Voltage type for actuating: | DC |
Nominal current: | 7 A |
Type of electric connection: | Plug-in connection |
Material of contact surface: | Silver |
Rated control supply voltage DC: | 24 - 24 V |
Degree of protection (IP): | IP20 |
With detachable clamps: | no |
Number of contacts as normally open contact: | 0 |
Number of contacts as change-over contact: | 2 |
Width: | 20 mm |
Drive, polarization: | Polarized |
With LED indication: | yes |
Drive, switching attitude: | Mono stable |
Depth: | 52 mm |
With forced-guided contacts: | no |
Number of contacts as normally closed contact: | 0 |
