Sterownik EtherNet/IP; 4. generacja; 2 x ETHERNET; ECO
Information | Value |
---|---|
Supplier | WAGO ELWAG Sp. z o.o. |
Symbol | 750-823 |
GTIN(EAN) | 4055143889094 |
Price unit | piece |
Catalog price | 1 988,91 zł (1 617,00 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Promotions related to this product
Description:
sterownik EtherNet/IP; 4. generacja; 2 x ETHERNET; ECO
Additional features:
Information | Value |
---|---|
Net weight: | 105,3 g |
ETIM class: | PLC CPU-module |
Type of memory: | FLASH |
Supporting protocol for AS-Interface Safety at Work: | no |
Explosion safety category for gas: | ATEX gas-ex-protection, Cat. 3G |
Explosion safety category for dust: | ATEX dust-ex-protection, Cat. 3D |
Supporting protocol for IEC 61850 Ethernet: | no |
Model: | Modular |
Supporting protocol for INTERBUS-Safety: | no |
Radio standard GPRS: | no |
Redundancy: | no |
Width: | 49.5 mm |
Radio standard GSM: | no |
Depth: | 71.9 mm |
Radio standard UMTS: | no |
Height: | 96.8 mm |
With display: | no |
Supporting protocol for SafetyBUS p: | no |
Supporting protocol for IEC 60870: | no |
Supporting protocol for DNP3: | no |
Supporting protocol for EtherNet/IP: | yes |
Supporting protocol for Foundation Fieldbus: | no |
Supporting protocol for DeviceNet Safety: | no |
Supporting protocol for PROFINET IO: | no |
Voltage type (supply voltage): | DC |
Supporting protocol for PROFIsafe: | no |
Long-Term Evolution (LTE): | no |
Supporting protocol for PROFINET CBA: | no |
Number of analogue outputs: | 0 |
Number of analogue inputs: | 0 |
Supporting protocol for LON: | no |
Appendant operation agent (Ex ib): | no |
Supporting protocol for CAN: | no |
Front built-in possible: | no |
Supporting protocol for INTERBUS: | no |
Radio standard Bluetooth: | no |
Supporting protocol for KNX: | no |
Radio standard WLAN 802.11: | no |
Supporting protocol for Modbus: | no |
Supporting protocol for Data-Highway: | no |
Rail mounting possible: | yes |
Supporting protocol for DeviceNet: | no |
Rack-assembly possible: | no |
Suitable for safety functions: | no |
Number of digital outputs: | 0 |
Number of digital inputs: | 0 |
Supporting protocol for TCP/IP: | no |
IO link master: | no |
Supporting protocol for ASI: | no |
Supporting protocol for PROFIBUS: | no |
Appendant operation agent (Ex ia): | no |
Supply voltage DC: | 24 - 24 V |
With optical interface: | no |
Additional program memory possible: | no |
System accessory: | yes |
Number of HW-interfaces wireless: | 0 |
Number of HW-interfaces industrial Ethernet: | 2 |
Number of HW-interfaces RS-232: | 0 |
Number of HW-interfaces RS-422: | 0 |
Number of HW-interfaces RS-485: | 0 |
Number of HW-interfaces USB: | 0 |
Number of interfaces PROFINET: | 0 |
Supporting protocol for SERCOS: | no |
Number of HW-interfaces parallel: | 0 |
Number of HW-interfaces other: | 0 |
Memory size: | 2048 kB |
Supporting protocol for SUCONET: | no |
Supporting protocol for other bus systems: | no |
Wall mounting/direct mounting: | no |
