Gniazdo 4-przewodowe PUSH WIRE®, szary
| Information | Value |
|---|---|
| Supplier | WAGO ELWAG Sp. z o.o. |
| Symbol | 243-744/000-007 |
| GTIN(EAN) | 4050821679431 |
| Price unit | piece |
| Catalog price | 6,77 zł (5,50 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
gniazdo 4-przewodowe; PUSH WIRE®; Ø 0,8 mm; raster 5,75 mm; 4-bieg.; do pojedynczych pinów lutowniczych; szary
Additional features:
| Information | Value |
|---|---|
| Net weight: | 3,1 g |
| ETIM class: | Printed circuit board terminal |
| Operating temperature: | -60 - 105 °C |
| Material insulation body: | Thermoplastic |
| Housing colour: | Grey |
| Rated current In: | 6 A |
| Material connection surface: | Tin |
| Rated surge voltage: | 4 kV |
| Type of PCB fastening: | Connecting contact |
| Rated voltage: | 320 V |
| Pollution degree: | 2 |
| Connection type PCB: | Soldering connection |
| Connection type conductor: | Push-in clamp connection |
| Length pin: | 4.5 mm |
| Modular spacing connections: | 5.75 mm |
| Type of banding: | None |
| Over voltage category: | III |
| Height: | 10 mm |
| Connectable conductor cross section solid-core: | 0.5 - 1 mm² |
| Diameter connection pin: | 1 mm |
| Inflammability class of insulation material according to with UL94: | V0 |
| Type of fastening: | Solder |
| Number of levels: | 1 |
| Angle PCB/conductor connection: | 0°/180° (horizontal) |
| Number of electrical connections: | 4 |
