Ex9B40J 3P B32 Wyłącznik nadprądowy typu slim, 6 kA, charakterystyka B, 32 A, 3-bieg.
Information | Value |
---|---|
Supplier | NOARK Electric Sp. z o.o. |
Symbol | 110750 |
GTIN(EAN) | 8592765107503 |
Price unit | piece |
Catalog price | 110,26 zł (89,64 zł + 23% VAT) |
Promotions related to this product
-
Are you reals ? !
Dokonaj zakupów produktów NOARK na kwotę powyżej 1500 zł brutto, a w prezencie otrzymasz Uchwyt Selfie marki VÖGEL BSF305K !
-
LETNIE ORZEŹWIENIE
Przy zakupach produktów NOARK w ElektRa Hurtownia Elektrotechniczna na kwotę 5000 zł brutto otrzymasz prezent Saturator Brita SodaOne
Additional features:
Information | Value |
---|---|
Net weight: | 258 g |
ETIM class: | Miniature circuit breaker (MCB) |
Voltage type: | AC |
Built-in depth: | 79 mm |
Rated current: | 32 A |
Rated voltage: | 400 V |
Frequency: | 50 - 60 Hz |
Release characteristic: | B |
Rated insulation voltage Ui: | 690 V |
Current limiting class: | 3 |
Over voltage category: | 3 |
Pollution degree: | 2 |
Width in number of modular spacings: | 2.25 |
Explosion-proof: | no |
Power loss: | 9.9 W |
Degree of protection (IP): | IP20 |
Number of protected poles: | 1 |
Concurrently switching neutral conductor: | no |
Connectable conductor cross section solid-core: | 1 - 16 mm² |
Ambient temperature during operating: | -25 - 70 °C |
Flush-mounted installation: | no |
Additional equipment possible: | yes |
Number of poles (total): | 1 |
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V: | 6 kA |
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V: | 6 kA |
Rated impulse withstand voltage Uimp: | 4 kV |
