STYCZNIK CTX3 3P 75A 2NO2NC 48V AC, Legrand
Information | Value |
---|---|
Supplier | Legrand Polska Sp. z o.o. |
Symbol | 416182 |
GTIN(EAN) | 3414970401489 |
Price unit | piece |
Catalog price | 1 233,51 zł (1 002,85 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Additional features:
Information | Value |
---|---|
ETIM class: | Power contactor, AC switching |
Rated operation current Ie at AC-1, 400 V: | 110 A |
Number of normally open contacts as main contact: | 3 |
Number of auxiliary contacts as normally open contact: | 2 |
Number of normally closed contacts as main contact: | 0 |
Rated operation power at AC-3, 400 V: | 37 kW |
Number of auxiliary contacts as normally closed contact: | 2 |
Rated operation current Ie at AC-4, 400 V: | 52 A |
Voltage type for actuating: | AC |
Rated operation power at AC-4, 400 V: | 25 kW |
Rated operation current Ie at AC-3, 400 V: | 75 A |
Modular version: | yes |
Rated control supply voltage AC 50 Hz: | 40.8 - 52.8 V |
Type of electrical connection of main circuit: | Cable clamp |
Rated control supply voltage AC 60 Hz: | 40.8 - 52.8 V |
