NZMB1-M63 Wyłącznik mocy 3-bieg.63A zabezpieczenie
Information | Value |
---|---|
Supplier | EATON Electric Sp. z o.o. (MOELLER) |
Symbol | 265712 |
GTIN(EAN) | 4015082657123 |
Price unit | piece |
Catalog price | 2 092,11 zł (1 700,90 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
Wyłączniki serii NZM..-M swoimi zaledwie czterema kompaktowymi wielkościami sprawdzają się we wszystkich zastosowaniach oraz nadają na rynek IEC. Montaż jest zawsze elastyczny za pomocą modułowych grup funkcyjnych. Z termomagnetycznym wyzwalaczem do ochrony silnika. Wskazówki: z wrażliwością na brak fazy, klasa wyzwolenia 10A, IEC/EN 60947-4-1, IEC/EN 60947-2 wyłączniki naprądowe spełniają wszystkie wymogi kategorii użytkowej AC-3.
Additional features:
Information | Value |
---|---|
Net weight: | 1,032 kg |
ETIM class: | Motor protection circuit-breaker |
Overload release current setting: | 50 - 63 A |
Adjustment range undelayed short-circuit release: | 504 - 882 A |
With thermal overload protection: | yes |
Phase failure sensitive: | yes |
Switch off technique: | Thermomagnetic |
Rated operating voltage: | 440 - 440 V |
Rated permanent current Iu: | 63 A |
Rated operation power at AC-3, 230 V: | 18.5 kW |
Rated operation power at AC-3, 400 V: | 30 kW |
Type of electrical connection of main circuit: | Other |
Type of control element: | Rocker lever |
Device construction: | Built-in device fixed built-in technique |
With integrated auxiliary switch: | no |
With integrated under voltage release: | no |
Number of poles: | 3 |
Rated short-circuit breaking capacity lcu at 400 V, AC: | 18.5 kA |
Degree of protection (IP): | IP20 |
Height: | 145 mm |
Width: | 90 mm |
Depth: | 88 mm |
