Ogranicznik przepięć DEHNrail M 2P 255 FM DR M 2P 255 FM
Information | Value |
---|---|
Supplier | DEHN Polska Sp. z o.o. |
Symbol | 953205 |
GTIN(EAN) | 4013364108318 |
Price unit | piece |
Catalog price | 509,40 zł (414,15 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Additional features:
Information | Value |
---|---|
Gross weight: | 98,88 g |
ETIM class: | Surge protection device for terminal equipment |
Nominal voltage AC: | 230 V |
Max. continuous voltage AC: | 255 V |
Max. continuous voltage DC: | 255 V |
Nominal load current: | 25 A |
Nominal discharge surge current (8/20) (L-N): | 3 kA |
Total discharge current (8/20) (L+N-PE): | 5 kA |
Voltage protection level L-N: | 1.25 kV |
Voltage protection level L-PE/N-PE: | 1.5 kV |
Max. overcurrent protection device, parallel connection (fuse): | 25 A |
Max. overcurrent protection device, series connection (fuse): | 25 A |
Number of poles: | 2 |
Mounting method: | DIN rail (top hat rail) 35 mm |
Max. conductor cross section solid (solid, stranded): | 4 mm² |
Max. conductor cross section flexible (fine-strand): | 2.5 mm² |
With remote signalling contact: | yes |
Signalling at the device: | Optical |
Category type 3: | yes |
With interference suppressor filter: | no |
Degree of protection (IP): | IP20 |
