2-przewodowa złączka do ekranu 16 mm², biała 283-908
| Information | Value |
|---|---|
| Supplier | WAGO ELWAG Sp. z o.o. |
| Symbol | 283-908 |
| GTIN(EAN) | 4045454084578 |
| Price unit | piece |
| Catalog price | 43,76 zł (35,58 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Promotions related to this product
Description:
złączka do ekranu 2-przewodowa; 16 mm²; opis na środku; na szynę TS 35 x 15 i 35 x 7,5; CAGE CLAMP®; 16,00 mm²; biały
Additional features:
| Information | Value |
|---|---|
| Net weight: | 46,57 g |
| ETIM class: | Ground terminal block |
| Operating temperature: | 105 - 105 °C |
| Material insulation body: | Thermoplastic |
| Height: | 94.5 mm |
| Connectable conductor cross section solid-core: | 0.2 - 16 mm² |
| PEN function possible: | no |
| Mounting method: | DIN rail (top hat rail) 35 mm |
| Inflammability class of insulation material according to with UL94: | V0 |
| Closing plate required: | yes |
| Type of electrical connection 1: | Spring clamp connection |
| Number of levels: | 1 |
| Type of electrical connection 2: | Spring clamp connection |
| Connectable conductor cross section fine-strand without cable end sleeve: | 0.2 - 16 mm² |
| Connectable conductor cross section multi-wired: | 0.2 - 16 mm² |
| Number of clamp positions per level: | 2 |
| Colour: | White |
| Width: | 12 mm |
| Depth: | 37.5 mm |
