ZP120 zacisk jednostronnie przebijający tor główny AsXs 35-120 mm2-tor od. Al 25-95mm2
Information | Value |
---|---|
Supplier | Tarnowskie Zakłady Osprzętu Elektrycznego TAREL sp. z o.o. |
Symbol | 9041-294 |
GTIN(EAN) | 5900280830821 |
Price unit | piece |
Catalog price | 68,14 zł (55,40 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Additional features:
Information | Value |
---|---|
Gross weight: | 3,25 kg |
ETIM class: | Branch terminal |
Nominal cross section main conductor, SE: | 35 - 120 mm² |
Nominal cross section main conductor, SM: | 35 - 120 mm² |
Nominal cross section branch conductor, SE/RE: | 25 - 95 mm² |
Nominal cross section branch conductor, SM/RM: | 25 - 95 mm² |
Material main conductor: | Aluminium |
Material branch conductor: | Aluminium |
Terminal insulated: | yes |
Clamping channel opening main conductor: | Both sides open |
Clamping channel opening branch conductor: | One side open |
Surface protection: | Bare |
Type of connection: | Insulation piercing connector IPC |
