Puszka do gniazd tablicowych prostych 16A,32A
| Information | Value |
|---|---|
| Supplier | Tarnowskie Zakłady Osprzętu Elektrycznego TAREL sp. z o.o. |
| Symbol | 056-I |
| GTIN(EAN) | 5903874955610 |
| Price unit | piece |
| Catalog price | 9,72 zł (7,90 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
Puszka do gniazd tablicowych prostych,16A,32A,średnica przewód max fi 25 mm,średnica wewnętrzna puszki fi 68 mm
Additional features:
| Information | Value |
|---|---|
| Net weight: | 60 g |
| ETIM class: | Box/housing for built-in mounting in the wall/ceiling |
| Mounting method: | Flush-mounted |
| Shape: | Square |
| Construction type: | Built-in installation box (device box) |
| Model: | Single |
| Provided with revolving ring: | no |
| Couplable: | no |
| Equipped with: | None |
| Diameter: | 68 mm |
| For number of electric fittings: | 1 |
| Mounting switching equipment: | Screwing |
| With screws: | no |
| Housing feed-through by break-out opening: | yes |
| Housing feed-through by seal membrane: | no |
| Housing feed-through by nozzle: | no |
| Housing feed-through by step membrane: | no |
| For tube diameter: | 25 mm |
| Suitable for cable diameter: | 2.5 - 25 mm |
| Pipe locking: | no |
| Pipe locking optional: | yes |
| Inlet from the rear: | no |
| Number of inlets: | 4 |
| Number of included spouts: | 0 |
| Material: | Plastic |
| Halogen free: | no |
| Surface protection: | Untreated |
| Colour: | Grey |
| Degree of protection (IP): | IPX4 |
| Sealable: | no |
| Circuit integrity: | None |
| With screening: | no |
| Air tight: | yes |
| Max. conductor cross section: | 25 mm² |
| Number of poles of the clamp: | 1 |
| Clamp position fixed: | no |
| Luminaire hook mounting: | no |
| Nozzle: | None |
| With nail lugs: | no |
| Special application: | None |
