Moduł Preventa UEP Kat.4 24V śrubowe
Information | Value |
---|---|
Supplier | Schneider Electric Polska Sp. z o.o. |
Symbol | XPSUEP14AP |
GTIN(EAN) | 3606489601775 |
Price unit | piece |
Catalog price | 986,46 zł (802,00 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
Ten przekaźnik bezpieczeństwa jest przeznaczony do rozszerzenia liczby styków bezpieczeństwa Przekaźnik bezpieczeństwa jest zasilany napięciem 24V AC/DC i wyposażony w blok zacisków z możliwością demontażu śrubowego. Ten uniwersalny moduł bezpieczeństwa zawiera wstępnie zdefiniowane funkcje bezpieczeństwa lub funkcje bezpieczeństwa wybierane za pomocą przełączników obrotowych. Ten przekaźnik bezpieczeństwa zawiera magistralę rozszerzenia bezpieczeństwa, 4 wyjścia bezpieczeństwa NO i 2 pojedyncze NC. Maksymalny poziom bezpieczeństwa osiągany przez ten przekaźnik bezpieczeństwa to PLe/Kategoria 4 zgodny z ISO 13849-1, SILCL 3 zgodny z IEC 62061, SIL 3 zgodny z IEC 61508. Jego wymiary to 22,5mm (szerokość) x 120mm (głębokość) x 100mm (wysokość). Jego wymiary to 22,5mm (szerokość) x 120mm (głębokość) x 100mm (wysokość). Ten przekaźnik bezpieczeństwa jest odpowiedni do zastosowań takich jak żywność i napoje, podnoszenie, przenoszenie materiałów, obróbka materiałów, pakowanie. Ten bezpieczny przekaźnik spełnia normy bezpieczeństwa funkcjonalnego IEC60947-5-1, IEC61508-1/2/3, ISO13849-1, IEC62061, posiada certyfikat cULus, TÜV, EAC, CCC oraz oznaczenie KC. XPSUEP może być używany tylko z modułami bezpieczeństwa XPSUAF, XPSUAK, XPSUAT, XPSUDN i XPSUS. Przekaźnik ten montowany jest na symetrycznej szynie DIN 35mm.
Additional features:
Information | Value |
---|---|
Gross weight: | 291 g |
ETIM class: | Device for monitoring of safety-related circuits |
With approval for BG BIA: | no |
Rail mounting possible: | yes |
Type of safety according to IEC 61496-1: | 4 |
Stop category according to IEC 60204: | 0 |
Depth: | 120 mm |
With approval for TÜV: | yes |
Width: | 22.5 mm |
Model: | Expansion device |
With muting function: | no |
With approval according to UL: | yes |
Type of electric connection: | Screw connection |
Suitable for monitoring of position switches: | no |
Number of outputs, signalling function, delayed, with contact: | 0 |
Release-delay: | 0 - 0 s |
Suitable for monitoring of valves: | no |
Suitable for monitoring of tactile sensors: | no |
Performance level according to EN ISO 13849-1: | Level e |
Evaluation inputs: | Other |
Number of outputs, signalling function, delayed, semiconductors: | 0 |
Height: | 100 mm |
Number of outputs, signalling function, undelayed, semiconductors: | 0 |
With start input: | no |
Number of outputs, safety related, undelayed, with contact: | 6 |
Suitable for monitoring of optoelectronic protection equipment: | no |
Suitable for monitoring of emergency-stop circuits: | no |
With feedback circuit: | no |
Number of outputs, safety related, undelayed, semiconductors: | 0 |
Number of outputs, safety related, delayed, with contact: | 0 |
Number of outputs, signalling function, undelayed, with contact: | 0 |
Number of outputs, safety related, delayed, semiconductors: | 0 |
SIL according to IEC 61508: | 3 |
Suitable for monitoring of proximity switches: | no |
Suitable for monitoring of magnetic switches: | no |
With detachable clamps: | yes |
Voltage type for actuating: | AC/DC |
Rated control supply voltage AC 50 Hz: | 24 - 24 V |
Rated control supply voltage AC 60 Hz: | 24 - 24 V |
Rated control supply voltage DC: | 24 - 24 V |
