Harmony Relay Przekaźnik półprzewodnikowy wejście 16/30VDC/wyjście 1/48VDC 0.1A
Information | Value |
---|---|
Supplier | Schneider Electric Polska Sp. z o.o. |
Symbol | SSL1D101BD |
GTIN(EAN) | 3606480579684 |
Price unit | piece |
Catalog price | 89,63 zł (72,87 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
Przekaźnik półprzewodnikowy dzięki swojej budowie nie wymaga konserwacji, jest cichy oraz może operować na wysokich częstotliwościach prze łączania. Jest odporny na uderzenia, kurz, wodoodporny i odporny na wibracje dzięki IP67, dzięki czemu idealnie nadaje się do pracy w trudnych warunkach.
Additional features:
Information | Value |
---|---|
Gross weight: | 4 g |
ETIM class: | Solid state relay |
Rated operation current Ie at AC-3: | 0.1 A |
Rated operation current Ie at AC-1: | 0.1 A |
Voltage type for actuating: | DC |
Rated control supply voltage DC: | 16 - 30 V |
Number of phases: | 1 |
Switching at zero-crossing: | no |
Rated operation current Ie at AC-53b: | 0.1 A |
Modular version: | yes |
Rated operation current Ie at AC-51: | 0.1 A |
Rated operation current Ie at AC-53a: | 0.1 A |
Operating voltage: | 1 - 48 V |
