MB6, siłownik zaworu, sprężyna powrotna, 6 Nm, sterowanie on/off, zasilanie 24 VAC, NO
| Information | Value |
|---|---|
| Supplier | Schneider Electric Polska Sp. z o.o. |
| Symbol | MB6-SO-24T |
| GTIN(EAN) | 711426559156 |
| Price unit | piece |
| Catalog price | 1 180,80 zł (960,00 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
Siłownik zaworu kulowego do zaworów kulowych VB200, VB210, VB300 i VB310. Górne złącze siłownika zapewnia szybkie i proste (bez użycia narzędzi) podłączenie siłownika do korpusu zaworu. sterowanie dwoma pozycjami. Sprężynowy zawór powrotny otwarty.
Additional features:
| Information | Value |
|---|---|
| Gross weight: | 1,5 kg |
| ETIM class: | Electric servomotor |
| Auxiliary contacts: | no |
| Explosion-proof: | no |
| Housing material: | Other |
| With top flange direct mount according to ISO 5211: | no |
| Self-adjusting travel length: | no |
| Degree of protection (IP): | IP53 |
| End contacts: | None |
| Auxiliary contacts optional: | no |
| Adjustable operating range: | no |
| Energy consumption in operation: | 2.3 W |
| Allowable relative humidity: | 5 - 95 % |
| Suitable for air accessory: | no |
| Automatic stroke recognition: | no |
| With safety function: | no |
| Suitable for valve: | yes |
| With mechanical setting indicator: | yes |
| Model: | Rotating |
| Deactivated when closed: | no |
| Max. electric power input: | 3.5 VA |
| Connection to stop valve: | Other |
| Return at zero supply voltage: | no |
| Adjustable position feedback signal: | no |
| Suitable for manual operation: | no |
| Control signal: | Other |
| Potential free switch contact: | no |
| Ambient temperature: | 0 - 76 °C |
| Regulation type splitrange: | no |
| Regulation type modulating: | no |
| Regulation type on/off: | yes |
| Position reporting system: | None |
| Torque: | 6 Nm |
| Supply voltage: | 24 V AC/DC |
| Degree of protection (NEMA): | 3 |
