Układ nawrotny TeSys K AC3, 6A, 3P, 1NC, cewka 110VAC, zaciski skrzynkowe
Information | Value |
---|---|
Supplier | Schneider Electric Polska Sp. z o.o. |
Symbol | LC2K0601F7 |
GTIN(EAN) | 3389110429411 |
Price unit | piece |
Catalog price | 731,46 zł (594,68 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Additional features:
Information | Value |
---|---|
Gross weight: | 366 g |
ETIM class: | Combination of contactors |
Rail mounting possible: | no |
Degree of protection (IP): | IP20 |
Rated operation current Ie at AC-3, 400 V: | 6 A |
Type of electrical connection for auxiliary- and control current circuit: | Screw connection |
Type of electrical connection of main circuit: | Screw connection |
Number of normally open contacts as main contact: | 3 |
Number of normally closed contacts as main contact: | 0 |
Voltage type for actuating: | AC |
Rated operation power NEMA: | 2.24 kW |
Rated control supply voltage AC 60 Hz: | 110 - 110 V |
Rated control supply voltage AC 50 Hz: | 110 - 110 V |
Function: | Reversing contactor |
Rated operation power at AC-3, 400 V: | 2.2 kW |
Degree of protection (NEMA): | Other |
