![Stycznik miniaturowy, TeSys K, I=6A [AC-3], cewka 230VAC, 50Hz, styk pom 1NO, zaciski skrzynkowe](https://www.megacennik.eu/plik/zdjecie/45844c8c74892cdcc870236bba6147fac5330731.jpg)
Stycznik miniaturowy, TeSys K, I=6A [AC-3], cewka 230VAC, 50Hz, styk pom 1NO, zaciski skrzynkowe
| Information | Value |
|---|---|
| Supplier | Schneider Electric Polska Sp. z o.o. |
| Symbol | LC1K0610P5 |
| GTIN(EAN) | 3606489602369 |
| Price unit | piece |
| Catalog price | 145,90 zł (118,62 zł + 23% VAT) |
| Sale price | from 42,36 zł / szt. (34,44 zł + 23 % VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
LC1K0610P5 to kompaktowy 3-biegunowy stycznik TeSys K firmy Schneider Electric do zastosowań silnikowych. Znamionowe 6A AC-3 2,2kW/400V, stycznik zawiera cewkę o napięciu sterującym 230V 50Hz AC i styk pomocniczy 1NO. • Znamionowy prąd łączeniowy AC-3 do 440V: 6A • Nap ięcie sterownia cewki: 230V AC • Liczba biegunów: 3 • Kategoria użytkowania zgodnie z IEC 60947-4-1: AC-3
Additional features:
| Information | Value |
|---|---|
| punkty elektroklub: | 10 |
| Gross weight: | 178,3 g |
| ETIM class: | Power contactor, AC switching |
| Type of electrical connection of main circuit: | Screw connection |
| Number of normally open contacts as main contact: | 3 |
| Number of normally closed contacts as main contact: | 0 |
| Number of auxiliary contacts as normally open contact: | 1 |
| Number of auxiliary contacts as normally closed contact: | 0 |
| Voltage type for actuating: | AC |
| Rated operation current Ie at AC-3, 400 V: | 6 A |
| Rated operation current Ie at AC-1, 400 V: | 20 A |
| Rated operation power NEMA: | 2.24 kW |
| Rated control supply voltage AC 50 Hz: | 230 - 230 V |
| Rated operation power at AC-3, 400 V: | 2.2 kW |
| Modular version: | yes |
| Rated operation power at AC-4, 400 V: | 2.2 kW |
| Rated operation current Ie at AC-4, 400 V: | 6 A |
