Stycznik mocy, TeSys Giga, 4 biegunowy (4NO), AC-1 <=440V 440A, wersja standardowa, 100…250V szerokozakresowa AC/DC cewka elektroniczna
| Information | Value |
|---|---|
| Supplier | Schneider Electric Polska Sp. z o.o. |
| Symbol | LC1G3304KUEN |
| GTIN(EAN) | 3606481922175 |
| Price unit | piece |
| Catalog price | 9 951,07 zł (8 090,30 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Additional features:
| Information | Value |
|---|---|
| Gross weight: | 9,1 kg |
| ETIM class: | Power contactor, AC switching |
| Type of electrical connection of main circuit: | Bolt connection |
| Number of normally open contacts as main contact: | 4 |
| Number of normally closed contacts as main contact: | 0 |
| Number of auxiliary contacts as normally open contact: | 1 |
| Number of auxiliary contacts as normally closed contact: | 1 |
| Voltage type for actuating: | AC/DC |
| Rated operation current Ie at AC-1, 400 V: | 440.0 A |
| Rated operation power NEMA: | 250 kW |
| Rated control supply voltage AC 60 Hz: | 100 - 250 V |
| Rated control supply voltage AC 50 Hz: | 100 - 250 V |
| Rated control supply voltage DC: | 100 - 250 V |
| Rated operation power at AC-3, 400 V: | 160.0 kW |
| Modular version: | no |
| Rated operation power at AC-4, 400 V: | 160.0 kW |
| Rated operation current Ie at AC-4, 400 V: | 330 A |
Unfortunately, this product is not available in any warehouse of any wholesaler of the EL-Plus group. However, you can contact the wholesaler of your choice and order it.
Order
Wholesaler
Address
Distance
Actions
Limanowa,
ul. Tarnowska 9D
Distance:
Gniezno,
ul. Słoneczna 40a
Distance:
Szaflary,
ul. Zakopiańska 18
Distance:
Additional information:
| Information | Value |
|---|---|
| Updated: | 2024-09-23 00:04:45 |
| Files to download: | |
| External links: |
