Wyłącznik silnikowy, TeSys GV4, 3P, 7A, Icu 100kA, thermal magnetyczny, końcówki oczkowe
Information | Value |
---|---|
Supplier | Schneider Electric Polska Sp. z o.o. |
Symbol | GV4PE07S6 |
GTIN(EAN) | 3606481310651 |
Price unit | piece |
Catalog price | 8 012,65 zł (6 514,35 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Additional features:
Information | Value |
---|---|
Gross weight: | 1,54 kg |
ETIM class: | Motor protection circuit-breaker |
Type of electrical connection of main circuit: | Screw connection |
Adjustment range undelayed short-circuit release: | 119 - 119 A |
Device construction: | Complete device in housing |
With integrated under voltage release: | no |
Number of poles: | 3 |
Degree of protection (IP): | IP40 |
Height: | 155 mm |
Rated operating voltage: | 690 - 690 V |
Depth: | 116 mm |
Width: | 81 mm |
Switch off technique: | Electronic |
Rated short-circuit breaking capacity lcu at 400 V, AC: | 100 kA |
Rated operation power at AC-3, 400 V: | 3 kW |
Phase failure sensitive: | yes |
With integrated auxiliary switch: | no |
Type of control element: | Rocker lever |
Rated permanent current Iu: | 7 A |
Overload release current setting: | 2.9 - 7 A |
With thermal overload protection: | yes |
Rated operation power at AC-3, 230 V: | 1.5 kW |
