Wyłącznik, ComPacT NSX, NSX100B, TM100D, 3P, 25kA
Information | Value |
---|---|
Supplier | Schneider Electric Polska Sp. z o.o. |
Symbol | C10B3TM100 |
GTIN(EAN) | 3606481996206 |
Price unit | piece |
Catalog price | 1 358,76 zł (1 104,68 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
C16F32D160 to 3-biegunowy wyłącznik mocy z serii ComPacT NSX firmy Schneider Electric o prądzie znamionowym 100A z wbudowanym zabezpieczeniem termomagnetycznym TM-D. Seria wyłączników ComPacT NSX 100 do 630 zapewnia wysokie parametry, a dzięki szerokiemu zakresowi wymie nnych zespołów zabezpieczeń nadaje się do większości zastosowań w dziedzinie zabezpieczeń instalacji i urządzeń elektrycznych. •Prąd znamionowy: 100A •Liczba biegunów: 3P •Zdolność wyłączania 380/415V: 25 kA •Typ wyzwalacza: Termomagnetyczny
Additional features:
Information | Value |
---|---|
Gross weight: | 1,785 kg |
ETIM class: | Power circuit-breaker for trafo/generator/installation protection |
Type of electrical connection of main circuit: | Screw connection |
Number of auxiliary contacts as change-over contact: | 0 |
Number of auxiliary contacts as normally open contact: | 0 |
Number of auxiliary contacts as normally closed contact: | 0 |
Adjustment range undelayed short-circuit release: | 800 - 800 A |
Integrated earth fault protection: | no |
Device construction: | Built-in device fixed built-in technique |
Suitable for DIN rail (top hat rail) mounting: | no |
With integrated under voltage release: | no |
Degree of protection (IP): | IP40 |
Number of poles: | 3 |
Rated voltage: | 690 - 690 V |
DIN rail (top hat rail) mounting optional: | yes |
Complete device with protection unit: | yes |
With switched-off indicator: | yes |
Motor drive integrated: | no |
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz: | 25 kA |
Overload release current setting: | 70 - 100 A |
Type of control element: | Toggle |
Rated permanent current Iu: | 100 A |
Adjustment range short-term delayed short-circuit release: | 800 - 800 A |
Motor drive optional: | yes |
Position of connection for main current circuit: | Front side |
