MD5, siłownik przepustnicy, 5 Nm, sterowanie on/off, zasilanie 24 VAC
| Information | Value |
|---|---|
| Supplier | Schneider Electric Polska Sp. z o.o. |
| Symbol | 8751005000 |
| GTIN(EAN) | 3606489659219 |
| Price unit | piece |
| Catalog price | 701,10 zł (570,00 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
MD5B to siłownik przepustnicy wł./wył. przeznaczony do obsługi przepustnic powietrza w systemach wentylacji i klimatyzacji w instalacjach usług budowlanych. Siłownik przepustnicy może być używany z zestawami montażowymi do napędzania wybranych zaworów motylkowych i szczękowych. Siłownik jest bezobsługowy, z mechanicznym wskazaniem pozycji. Napięcie zasilania: 24 Vac/Vdc +/- 2%. Sygnał sterujący: on/off. Moment dokręcenia: 5 Nm, stopień ochrony IP 54. Kąt obrotu: Maks. 95°, regulowane za pomocą blokad mechanicznych. Kabel połączeniowy 1 m, 3 x 75 mm² (AW 18).
Additional features:
| Information | Value |
|---|---|
| Gross weight: | 500 g |
| ETIM class: | Electric servomotor |
| Auxiliary contacts: | yes |
| Explosion-proof: | no |
| Housing material: | Other |
| Max. angle of rotation: | 95 ° |
| With top flange direct mount according to ISO 5211: | no |
| Degree of protection (IP): | IP54 |
| End contacts: | 1 |
| Auxiliary contacts optional: | no |
| Adjustable operating range: | yes |
| Energy consumption in operation: | 1 W |
| Allowable relative humidity: | 0 - 95 % |
| Principle of operation safety function: | NO/NC (depends on mounting) |
| Suitable for air accessory: | yes |
| Type of safety function: | Other |
| Automatic stroke recognition: | no |
| With safety function: | yes |
| Connection cable length: | 1 m |
| Width: | 114 mm |
| Suitable for valve: | no |
| With mechanical setting indicator: | yes |
| Model: | Rotating |
| Deactivated when closed: | no |
| Max. electric power input: | 1.5 VA |
| Connection to stop valve: | None |
| Return at zero supply voltage: | no |
| Adjustable position feedback signal: | no |
| Suitable for manual operation: | yes |
| Control signal: | Binary |
| Potential free switch contact: | yes |
| Ambient temperature: | -30 - 50 °C |
| Regulation type splitrange: | no |
| Regulation type modulating: | no |
| Regulation type on/off: | yes |
| Height: | 69 mm |
| Operating time: | 150 s |
| Position reporting system: | None |
| Torque: | 5 Nm |
| Supply voltage: | 24 V AC/DC |
| Degree of protection (NEMA): | 3 |
