SPW1xx, przetwornik różnicy ciśnień cieczy, 0…1,6 bar (0-10V)
Information | Value |
---|---|
Supplier | Schneider Electric Polska Sp. z o.o. |
Symbol | 6552049000 |
GTIN(EAN) | 7332552012761 |
Price unit | piece |
Catalog price | 4 735,50 zł (3 850,00 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
Czujniki różnicy ciśnień na mokro SPW wykorzystują sprawdzoną technologię ceramiczną. Charakteryzują się niską czułością na zmiany temperatury i wysoką odpornością na ekstremalne temperatury.
Additional features:
Information | Value |
---|---|
Gross weight: | 660 g |
ETIM class: | Differential pressure transformer |
Nominal pressure rating according to EN 1333 (PN ...): | 16 |
Nominal pressure rating according to ASME B16.5 (Class ...): | 150 |
Ambient temperature: | -15 - 85 °C |
Nominal pressure rating according to EN 1333 at H-side (PN ...): | 16 |
Weight: | 0.43 kg |
Nominal pressure rating according to ASME B16.5 at H-side (Class ...): | 150 |
Measuring range: | 0 - 1.6 bar |
Nominal pressure rating according to EN 1333 at L-side (PN ...): | 16 |
Analogue output 0 mA ... 20 mA: | no |
Nominal pressure rating according to ASME B16.5 at L-side (Class ...): | 150 |
Analogue output 0 V ... 10 V: | yes |
Analogue output 0 V ... 2 V: | no |
Analogue output 0 V ... 5 V: | no |
Analogue output 2 V ... 10 V: | no |
Analogue output 4 mA ... 20 mA: | no |
