Przekaźnik czasowy RPC-1IP-UNI
Information | Value |
---|---|
Supplier | RELPOL S.A. |
Symbol | 863189 |
GTIN(EAN) | 5900005230455 |
Price unit | piece |
Catalog price | 252,62 zł (205,38 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
Przekaźnik jednofunkcyjny- dwuczasowy. Funkcja li + lp - praca cykliczna o dwóch niezależnych czasach T1 i T2. Praca z funkcją li lub lp zależna od stanu zestyku sterującego S. 8 zakresów czasowych. Wyjście: 1P - jeden styk przełączny. Napięcie zasilania - uniwersalne: 12...240VAC/DC 50/60 Hz
Additional features:
Information | Value |
---|---|
Net weight: | 66 g |
ETIM class: | Timer relay |
Nominal current: | 16 A |
Width: | 17.5 mm |
Height: | 90 mm |
Depth: | 64.5 mm |
Remote operation possible: | no |
Suitable as remote control: | no |
Function flashing, starting with pause, fixed time: | yes |
Function flashing, starting with pulse, fixed time: | yes |
Clock function, starting with pause, variable: | no |
Clock function, starting with pulse, variable: | no |
With semiconductor output: | no |
Function delay-on energization: | no |
Function floating contact on energization: | no |
Function star-delta: | no |
Time range: | 0.1 - 864000 s |
Function delay on de-energization: | no |
Function floating contact on de-energization: | no |
Function pulse shaping: | no |
Type of electric connection: | Screw connection |
Rated control supply voltage AC 50 Hz: | 12 - 240 V |
Rated control supply voltage AC 60 Hz: | 12 - 240 V |
Rated control supply voltage DC: | 12 - 240 V |
Number of outputs, undelayed, normally closed contact: | 0 |
Number of outputs, undelayed, normally open contact: | 0 |
Number of outputs, undelayed, change-over contact: | 1 |
Number of outputs, delayed, normally closed contact: | 0 |
Number of outputs, delayed, normally open contact: | 0 |
Number of outputs, delayed, change-over contact: | 1 |
Pluggable on auxiliary contact block: | no |
Outputs, reversible delayed/undelayed: | no |
Suitable for DIN rail (top hat rail) mounting: | yes |
Voltage type for actuating: | AC/DC |
