Przekaźnik czasowy RPC-2MA-UNI
| Information | Value |
|---|---|
| Supplier | RELPOL S.A. |
| Symbol | 863183 |
| GTIN(EAN) | 5900005230271 |
| Price unit | piece |
| Catalog price | 244,78 zł (199,01 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
Wielofunkcyjny przekaźnik czasowy - 10 funkcji czasowych E, Wu, Bp, Bi, R, Ws, Wa, Esa, B, T; 8 zakresów czasowych, Wyjście: 2P - dwa styki przełączne. Napięcie zasilania - uniwersalne: 12...240VAC/DC 50/60 Hz. Minimalna moc łączeniowa 1 W 10 mA
Additional features:
| Information | Value |
|---|---|
| Net weight: | 73 g |
| ETIM class: | Timer relay |
| Nominal current: | 16 A |
| Width: | 17.5 mm |
| Height: | 90 mm |
| Depth: | 64.5 mm |
| Remote operation possible: | no |
| Suitable as remote control: | no |
| Function flashing, starting with pause, fixed time: | yes |
| Function flashing, starting with pulse, fixed time: | yes |
| Clock function, starting with pause, variable: | yes |
| Clock function, starting with pulse, variable: | yes |
| With semiconductor output: | no |
| Function delay-on energization: | yes |
| Function floating contact on energization: | yes |
| Function star-delta: | no |
| Time range: | 0.1 - 864000 s |
| Function delay on de-energization: | yes |
| Function floating contact on de-energization: | yes |
| Function pulse shaping: | yes |
| Type of electric connection: | Screw connection |
| Rated control supply voltage AC 50 Hz: | 12 - 240 V |
| Rated control supply voltage AC 60 Hz: | 12 - 240 V |
| Rated control supply voltage DC: | 12 - 240 V |
| Number of outputs, undelayed, normally closed contact: | 0 |
| Number of outputs, undelayed, normally open contact: | 0 |
| Number of outputs, undelayed, change-over contact: | 2 |
| Number of outputs, delayed, normally closed contact: | 0 |
| Number of outputs, delayed, normally open contact: | 0 |
| Number of outputs, delayed, change-over contact: | 2 |
| Pluggable on auxiliary contact block: | no |
| Outputs, reversible delayed/undelayed: | no |
| Suitable for DIN rail (top hat rail) mounting: | yes |
| Voltage type for actuating: | AC/DC |
