Przekaźnik przemysłowy RS35-3022-25-1005
| Information | Value |
|---|---|
| Supplier | RELPOL S.A. |
| Symbol | 859166 |
| Price unit | piece |
| Catalog price | 136,97 zł (111,36 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
Przekaźnik do inwerterów solarnych i aplikacji wysokoprądowych - 2 zestyki zwierne (2Z) - obciążalność prądowa trwała zestyku: 35 A. Cewka 5 V DC. Znamionowy prąd obciążenia w kategorii AC1: 35 A / 250 V AC, DC: 35 A / 24 V DC. Maksymalne napięcie zestyków: 440 V AC. Minimalny prąd zestyków: 10 mA. Przerwa zestykowa ≥ 2, 2 mm. Maksymalna moc łączeniowa w kategorii AC1: 8 750 VA. Do obwodów drukowanych
Additional features:
| Information | Value |
|---|---|
| Net weight: | 105 g |
| ETIM class: | Switching relay |
| Type of electric connection: | PCB connection |
| With detachable clamps: | no |
| Nominal current: | 35 A |
| Rated control supply voltage AC 50 Hz: | 0 - 0 V |
| Rated control supply voltage AC 60 Hz: | 0 - 0 V |
| Rated control supply voltage DC: | 5 - 5 V |
| Voltage type for actuating: | DC |
| Drive, polarization: | Polarity free |
| Drive, switching attitude: | Mono stable |
| Number of contacts as normally closed contact: | 0 |
| Number of contacts as normally open contact: | 2 |
| Number of contacts as change-over contact: | 0 |
| With forced-guided contacts: | no |
| Type of switch contact: | Single contact |
| Complete with socket: | no |
| With LED indication: | no |
| Material of contact surface: | Silver |
| Degree of protection (IP): | IP40 |
| Width: | 25 mm |
| Height: | 49.2 mm |
| Depth: | 40 mm |
