Przekaźnik czasowy PIR6WBT-1Z-115VAC-C
| Information | Value |
|---|---|
| Supplier | RELPOL S.A. |
| Symbol | 857691 |
| GTIN(EAN) | 5900005050503 |
| Price unit | piece |
| Catalog price | 240,83 zł (195,80 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
Przekaźnik czasowy wąskoprofilowy, wielofunkcyjny: 1Z - jedno wyjście tranzystorowe 1 A. Szerokość 6,2 mm. Funkcje: E, Wu, Bi, Bp, R, Ws, Wa, Esa, B, OFF - stałe wyłączenie. Zaciski sprężynowe. Wyjście (wymienne - przekaźnik RSR30, oznaczenie w kodzie "C"): tranzystor 1Z - zaciski: (+)17 - (-)18, DC1 - 1 A / 48 V. Wejście - zaciski: A1 - A2; zewnętrzny zestyk sterujący S - zaciski: S(A3) - A1, napięcie zasilania Un - 115 V AC Wymiary: 98,3 x 6,2 x 84,6 mm. Montaż na szynie 35 mm. Obudowa kompaktowa. IP 20.
Additional features:
| Information | Value |
|---|---|
| Net weight: | 60 g |
| ETIM class: | Timer relay |
| Type of electric connection: | Screw connection |
| Function delay-on energization: | yes |
| Function delay on de-energization: | yes |
| Function floating contact on energization: | yes |
| Function floating contact on de-energization: | yes |
| Function star-delta: | yes |
| Function pulse shaping: | no |
| Function flashing, starting with pause, fixed time: | yes |
| Function flashing, starting with pulse, fixed time: | yes |
| Clock function, starting with pause, variable: | yes |
| Clock function, starting with pulse, variable: | yes |
| Remote operation possible: | no |
| Suitable as remote control: | no |
| Pluggable on auxiliary contact block: | no |
| Rated control supply voltage AC 50 Hz: | 115 - 115 V |
| Rated control supply voltage AC 60 Hz: | 115 - 115 V |
| Rated control supply voltage DC: | 0 - 0 V |
| Voltage type for actuating: | AC |
| Nominal current: | 1 A |
| Time range: | 1 - 864000 s |
| Number of outputs, undelayed, normally closed contact: | 0 |
| Number of outputs, undelayed, normally open contact: | 1 |
| Number of outputs, undelayed, change-over contact: | 0 |
| Number of outputs, delayed, normally closed contact: | 0 |
| Number of outputs, delayed, normally open contact: | 1 |
| Number of outputs, delayed, change-over contact: | 0 |
| Outputs, reversible delayed/undelayed: | no |
| With semiconductor output: | no |
| Suitable for DIN rail (top hat rail) mounting: | yes |
| Width: | 6.2 mm |
| Height: | 84.6 mm |
| Depth: | 98.3 mm |
| Suitable for front mounting: | no |
