Przekaźnik interfejsowy PIR6W-1PS-42VAC/DC-R01
Information | Value |
---|---|
Supplier | RELPOL S.A. |
Symbol | 857180 |
Price unit | piece |
Catalog price | 109,96 zł (89,40 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
Przekaźnik interfejsowy wąskoprofilowy: 1P - jeden zestyk przełączny, styki złocone. Szerokość 6,2 mm. Zaciski śrubowe. Wyjście (wymienne - przekaźnik RM699BV, oznaczenie w kodzie "R01"): styki 1P - zaciski: 11-12-14; AC1 - 50 mA / 30 V; DC1 - 50 mA / 36 V. Wejście - zaciski: A1 - A2 - dowolna biegunowość, napięcie zasilania Un - 42 V AC/DC. Wymiary: 98,5 x 6,2 x 85,5 mm. Montaż na szynie 35 mm. IP 20.
Additional features:
Information | Value |
---|---|
Net weight: | 45 g |
ETIM class: | Switching relay |
Type of electric connection: | Screw connection |
Complete with socket: | yes |
With detachable clamps: | no |
With LED indication: | no |
Rated control supply voltage AC 50 Hz: | 42 - 42 V |
Rated control supply voltage AC 60 Hz: | 42 - 42 V |
Rated control supply voltage DC: | 42 - 42 V |
Voltage type for actuating: | AC/DC |
Drive, polarization: | Polarity free |
Drive, switching attitude: | Mono stable |
Number of contacts as normally closed contact: | 0 |
Number of contacts as normally open contact: | 0 |
Number of contacts as change-over contact: | 1 |
Type of switch contact: | Single contact |
With forced-guided contacts: | no |
Material of contact surface: | Silver |
Nominal current: | 0.05 A |
Degree of protection (IP): | IP20 |
Width: | 6.2 mm |
Height: | 85.5 mm |
Depth: | 98.5 mm |
Unfortunately, this product is not available in any warehouse of any wholesaler of the EL-Plus group. However, you can contact the wholesaler of your choice and order it.
Order
Wholesaler
Address
Distance
Actions
Przedsiębiorstwo Wielobranżowe „ELEKTRO-HURT” Aleksander Winter Sp. z o.o.
Gniezno,
ul. Słoneczna 40a
Distance:
Firma Handlowo-Usługowa "LUX-SYSTEM" S.M. Stanek, J.E. Poniedziałek Sp.j.
Szaflary,
ul. Zakopiańska 18
Distance:
Firma Handlowa "ELEKTRET" Spółka komandytowa Jacek Bieda, Agata Mól
Limanowa,
ul. Tarnowska 9D
Distance:
Additional information:
Information | Value |
---|---|
Updated: | 2024-07-19 00:03:08 |
Files to download: |
