Przekaźnik Interfejsowy PIR6W-1P-230VAC/DC
| Information | Value |
|---|---|
| Supplier | RELPOL S.A. |
| Symbol | 856069 |
| Price unit | piece |
| Catalog price | 110,71 zł (90,01 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
Przekaźnik interfejsowy wąskoprofilowy: 1P - jeden zestyk przełączny. Szerokość 6,2 mm. Zaciski śrubowe. Wyjście (wymienne - przekaźnik RM699BV): styki 1P - zaciski: 11-12-14; AC1 - 6 A / 230 V; DC1 - 6 A / 24 V. Wejście - zaciski: A1 - A2 - dowolna biegunowość, napięcie zasilania Un - 230 V AC/DC. Wymiary: 98,5 x 6,2 x 85,5 mm. Montaż na szynie 35 mm. IP 20.
Additional features:
| Information | Value |
|---|---|
| Net weight: | 45 g |
| ETIM class: | Switching relay |
| Nominal current: | 6 A |
| Width: | 6.2 mm |
| Height: | 85.5 mm |
| Depth: | 98.5 mm |
| With detachable clamps: | no |
| Drive, polarization: | Polarity free |
| Drive, switching attitude: | Mono stable |
| With forced-guided contacts: | no |
| Type of switch contact: | Single contact |
| Complete with socket: | yes |
| Type of electric connection: | Screw connection |
| Rated control supply voltage AC 50 Hz: | 230 - 230 V |
| Rated control supply voltage AC 60 Hz: | 230 - 230 V |
| Rated control supply voltage DC: | 230 - 230 V |
| Material of contact surface: | Silver |
| Degree of protection (IP): | IP20 |
| With LED indication: | no |
| Voltage type for actuating: | AC/DC |
| Number of contacts as normally closed contact: | 0 |
| Number of contacts as normally open contact: | 0 |
| Number of contacts as change-over contact: | 1 |
