Przekaźnik czasowy T-R4E-2014-23-1024
| Information | Value |
|---|---|
| Supplier | RELPOL S.A. |
| Symbol | 854941 |
| GTIN(EAN) | 5900005161544 |
| Price unit | piece |
| Catalog price | 188,69 zł (153,41 zł + 23% VAT) |
| Sale price | from 64,64 zł / szt. (52,55 zł + 23 % VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
Przekaźnik czasowy, jednofunkcyjny: 4P - cztery zestyki przełączne. Funkcja E - opóźnione załączenie. Wejście - zaciski: (-)A1 - (+)A2, napięcie zasilania Un - 24 V DC. Wyjście: zestyki 4P - zaciski: 11(9)-12(1)-14(5), 21(10)-22(2)-24(6), 31(11)-32(3)-34(7), 41(12)-42(4)-44(8), AC1 - 6 A / 230 V. Do gniazda wtykowego GZM4 lub GZT4.
Additional features:
| Information | Value |
|---|---|
| Net weight: | 49 g |
| ETIM class: | Timer relay |
| Type of electric connection: | Plug-in connection |
| Function delay-on energization: | yes |
| Function delay on de-energization: | no |
| Function floating contact on energization: | no |
| Function floating contact on de-energization: | no |
| Function star-delta: | no |
| Function pulse shaping: | no |
| Function flashing, starting with pause, fixed time: | no |
| Function flashing, starting with pulse, fixed time: | no |
| Clock function, starting with pause, variable: | no |
| Clock function, starting with pulse, variable: | no |
| Remote operation possible: | no |
| Suitable as remote control: | no |
| Pluggable on auxiliary contact block: | no |
| Rated control supply voltage AC 50 Hz: | 0 - 0 V |
| Rated control supply voltage AC 60 Hz: | 0 - 0 V |
| Rated control supply voltage DC: | 24 - 24 V |
| Voltage type for actuating: | DC |
| Nominal current: | 6 A |
| Number of outputs, undelayed, normally closed contact: | 0 |
| Number of outputs, undelayed, normally open contact: | 0 |
| Number of outputs, undelayed, change-over contact: | 0 |
| Number of outputs, delayed, normally closed contact: | 0 |
| Number of outputs, delayed, normally open contact: | 0 |
| Number of outputs, delayed, change-over contact: | 4 |
| Outputs, reversible delayed/undelayed: | no |
| With semiconductor output: | no |
| Width: | 21.2 mm |
| Height: | 62.5 mm |
| Depth: | 27.5 mm |
