Przekaźnik miniaturowy RM12N-2211-25-1012
Information | Value |
---|---|
Supplier | RELPOL S.A. |
Symbol | 2616972 |
Price unit | piece |
Catalog price | 17,54 zł (14,26 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
Przekaźnik elektromagnetyczny, miniaturowy, do obwodu drukowanego. Wysokość 12,5 mm. Wyjście: 1P - jeden zestyk przełączny - wyprowadzenia: 11-12-14; 8 A / 250 V; DC1 - 8 A / 30 V. Wejście / cewka - wyprowadzenia: A1 - A2, napięcie zasilania Un - 12 V DC. Wymiary: 28,5 x 10,1 x 12,5mm. IP 40. Materiał styków: AgNi złocenie.
Additional features:
Information | Value |
---|---|
Net weight: | 8 g |
ETIM class: | Switching relay |
Complete with socket: | no |
With LED indication: | no |
Rated control supply voltage AC 50 Hz: | 0 - 0 V |
Rated control supply voltage AC 60 Hz: | 0 - 0 V |
Rated control supply voltage DC: | 12 - 12 V |
Voltage type for actuating: | DC |
Drive, polarization: | Polarity free |
Drive, switching attitude: | Mono stable |
Number of contacts as normally closed contact: | 0 |
Number of contacts as normally open contact: | 0 |
Number of contacts as change-over contact: | 1 |
Type of switch contact: | Single contact |
With forced-guided contacts: | no |
Material of contact surface: | Gold |
Nominal current: | 8 A |
Degree of protection (IP): | IP40 |
Width: | 10.3 mm |
Height: | 12.7 mm |
Depth: | 28.7 mm |
Material contact: | Silver nickel (AgNi) |
