Przekaźnik miniaturowy RM12N-2011-35-1006
Information | Value |
---|---|
Supplier | RELPOL S.A. |
Symbol | 2614988 |
Price unit | piece |
Catalog price | 15,60 zł (12,68 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
Przekaźnik elektromagnetyczny, miniaturowy, do obwodu drukowanego. Wysokość 12,5 mm. Wyjście: 1P - jeden zestyk przełączny - wyprowadzenia: 11-12-14; obciążalność 8 A / 250 V; DC1 - 8 A / 30 V. Wejście / cewka - wyprowadzenia: A1 - A2, napięcie zasilania Un - 6 V DC. Wymiary: 28,5 x 10,1 x 12,5 mm. IP 67. Materiał styków: AgNi.
Additional features:
Information | Value |
---|---|
Net weight: | 8 g |
ETIM class: | Switching relay |
Complete with socket: | no |
With LED indication: | no |
Rated control supply voltage AC 50 Hz: | 0 - 0 V |
Rated control supply voltage AC 60 Hz: | 0 - 0 V |
Rated control supply voltage DC: | 6 - 6 V |
Voltage type for actuating: | DC |
Drive, polarization: | Polarity free |
Drive, switching attitude: | Mono stable |
Number of contacts as normally closed contact: | 0 |
Number of contacts as normally open contact: | 0 |
Number of contacts as change-over contact: | 1 |
Type of switch contact: | Single contact |
With forced-guided contacts: | no |
Material of contact surface: | Gold |
Nominal current: | 8 A |
Degree of protection (IP): | IP67 |
Width: | 10.3 mm |
Height: | 12.7 mm |
Depth: | 28.7 mm |
Material contact: | Silver nickel (AgNi) |
Unfortunately, this product is not available in any warehouse of any wholesaler of the EL-Plus group. However, you can contact the wholesaler of your choice and order it.
Order
Wholesaler
Address
Distance
Actions
Firma Handlowa "ELEKTRET" Spółka komandytowa Jacek Bieda, Agata Mól
Limanowa,
ul. Tarnowska 9D
Distance:
Przedsiębiorstwo Wielobranżowe „ELEKTRO-HURT” Aleksander Winter Sp. z o.o.
Gniezno,
ul. Słoneczna 40a
Distance:
Firma Handlowo-Usługowa "LUX-SYSTEM" S.M. Stanek, J.E. Poniedziałek Sp.j.
Szaflary,
ul. Zakopiańska 18
Distance:
Additional information:
Information | Value |
---|---|
Updated: | 2024-07-19 00:03:04 |
Files to download: |
