Przekaźnik sygnałowy RSM954N-0111-85-1009
| Information | Value |
|---|---|
| Supplier | RELPOL S.A. |
| Symbol | 2614626 |
| Price unit | piece |
| Catalog price | 9,30 zł (7,56 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
Przekaźniki RSM954N, monostabilne, 1 zestyk przełączny, 3 A, do obwodów drukowanych. Wejście / cewka: 6-7, napięcie zasilania Un - 9 V DC
Additional features:
| Information | Value |
|---|---|
| Net weight: | 3,5 g |
| ETIM class: | Switching relay |
| Type of electric connection: | PCB connection |
| With detachable clamps: | no |
| Nominal current: | 3 A |
| Rated control supply voltage AC 50 Hz: | 0 - 0 V |
| Rated control supply voltage AC 60 Hz: | 0 - 0 V |
| Rated control supply voltage DC: | 9 - 9 V |
| Voltage type for actuating: | DC |
| Drive, polarization: | Polarity free |
| Drive, switching attitude: | Mono stable |
| Number of contacts as normally closed contact: | 0 |
| Number of contacts as normally open contact: | 0 |
| Number of contacts as change-over contact: | 1 |
| With forced-guided contacts: | no |
| Type of switch contact: | Single contact |
| Complete with socket: | no |
| With LED indication: | no |
| Material of contact surface: | Gold |
| Degree of protection (IP): | IP67 |
| Width: | 11 mm |
| Height: | 11.5 mm |
| Depth: | 15.5 mm |
| Material contact: | Other |
