Stycznik instalacyjny RIK21-01-24
| Information | Value |
|---|---|
| Supplier | RELPOL S.A. |
| Symbol | 2608177 |
| Price unit | piece |
| Catalog price | 170,45 zł (138,58 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
Stycznik instalacyjny, 3-biegunowy, 3 N/O (1-2, 3-4, 5-6) + zestyk pomocniczy 1 N/Z (21-22). Ui - 415 V. Ith - 20 A. AC1/AC7a - 7,5 kW / 230 V; 13 kW / 400 V. AC3/AC7b - 1,1 kW / 230 V; 2,2 kW / 400 V. Cewka 24 V AC - zaciski: A1 - A2. Wymiary: 62,5 x 35 x 57 mm. Montaż na szynie 35 mm. IP 20.
Additional features:
| Information | Value |
|---|---|
| Net weight: | 170 g |
| ETIM class: | Installation contactor for distribution board |
| Rated operating voltage: | 400 - 400 V |
| Rated operation current: | 5 A |
| Rated excitation voltage: | 24 - 230 V |
| Voltage type (operating voltage): | AC |
| Voltage type (excitation voltage): | AC |
| Number of contacts as normally open contact: | 3 |
| Number of contacts as normally closed contact: | 0 |
| Slider for hand switch: | no |
| Width in number of modular spacings: | 2 |
| Built-in depth: | 59.5 mm |
| Degree of protection (IP): | IP20 |
