LZ-B4/2 ZŁĄCZKA K. CZARNY
Information | Value |
---|---|
Supplier | POKÓJ S.E. |
Symbol | A12-0A53 |
GTIN(EAN) | 5907570305939 |
Price unit | piece |
Catalog price | 12,90 zł (10,49 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Additional features:
Information | Value |
---|---|
ETIM class: | Single- and multi-pole terminal strip |
Drill hole distance centrically: | 7.4 mm |
Explosion-tested version 'Ex e': | no |
Connectable conductor cross section fine-strand without cable end sleeve: | 0.75 - 2.5 mm² |
Connectable conductor cross section fine-strand with cable end sleeve: | 0.75 - 2.5 mm² |
Connectable conductor cross section solid-core: | 0.75 - 4 mm² |
Connectable conductor cross section multi-wired: | 0.75 - 2.5 mm² |
Rated current In: | 32 A |
Rated voltage: | 500 V |
Type of electrical connection 1: | Screw connection |
Type of electrical connection 2: | Screw connection |
Connection position: | Atop |
Number of poles: | 2 |
Number of clamp positions per pole: | 2 |
Mounting method: | Direct mounting |
Material insulation body: | Other |
Operating temperature: | -25 - 150 °C |
Inflammability class of insulation material according to with UL94: | V2 |
Width/grid dimension: | 22.5 mm |
Length: | 20 mm |
Closing plate required: | no |
Colour: | Black |
Transparent: | no |
