74 CE SW/EKL 1 S Złączka zaciskowa 12-torowa 6mm2
| Information | Value |
|---|---|
| Supplier | OBO Bettermann Polska Sp. z o.o. |
| Symbol | 2056232 |
| GTIN(EAN) | 4012195879312 |
| Price unit | piece |
| Catalog price | 6,35 zł (5,16 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
Atestowany zgodnie z normą EN 60998.
Stalowe zaciski, stalowe śruby, ocynkowane, 12-biegunowe zaciski, które można rozdzielić na pojedyncze.
Śruby wysoko wykręcane, bez możliwości zgubienia.
Maksymalna dopuszczalna temperatura otoczenia zgodnie z EN 60998: -5 do +80 ° C.
Przekrój nominalny 6 mm²
Napięcie znamionowe 450 V
Prąd znamionowy 41 A
Maks. zacisk na stronę: pojedynczy drut 6 mm² lub cienki drut 4 mm².
Additional features:
| Information | Value |
|---|---|
| ETIM class: | Single- and multi-pole terminal strip |
| Drill hole distance centrically: | 10 mm |
| Connectable conductor cross section fine-strand without cable end sleeve: | 1.5 - 4 mm² |
| Connectable conductor cross section solid-core: | 1.5 - 6 mm² |
| Type of electrical connection 1: | Screw connection |
| Type of electrical connection 2: | Screw connection |
| Number of poles: | 12 |
| Number of clamp positions per pole: | 2 |
| Mounting method: | Direct mounting |
| Operating temperature: | -5 - 80 °C |
| Width: | 18.9 mm |
| Height: | 14.9 mm |
| Closing plate required: | no |
| Colour: | Black |
| Transparent: | no |
| Rated current In: | 41 A |
| Rated voltage: | 450 V |
| Depth: | 116.5 mm |
