Rated short-circuit breaking capacity lcu at 400 V, 50 Hz:
50 kA
Overload release current setting:
87 - 125 A
Adjustment range undelayed short-circuit release:
625 - 1250 A
Power loss:
35.6 W
Device construction:
Built-in device fixed built-in technique
Integrated earth fault protection:
no
Type of electrical connection of main circuit:
Screw connection
Suitable for DIN rail (top hat rail) mounting:
no
DIN rail (top hat rail) mounting optional:
yes
With switched-off indicator:
no
With integrated under voltage release:
no
Number of poles:
2
Position of connection for main current circuit:
Front side
Type of control element:
Rocker lever
Complete device with protection unit:
yes
Motor drive integrated:
no
Motor drive optional:
yes
Degree of protection (IP):
IP20
