Ex9M2Q TM 160 2P EU Wyłącznik kompaktowy AC, termomagnetyczny, wielkość M2, Icu=Ics=75kA, In=160A, 2P
Information | Value |
---|---|
Supplier | NOARK Electric Sp. z o.o. |
Symbol | 114052 |
GTIN(EAN) | 8592765140524 |
Price unit | piece |
Catalog price | 1 868,03 zł (1 518,72 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Promotions related to this product
Additional features:
Information | Value |
---|---|
Net weight: | 1,3 kg |
ETIM class: | Power circuit-breaker for trafo/generator/installation protection |
Rated permanent current Iu: | 160 A |
Rated voltage: | 415 - 690 V |
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz: | 70 kA |
Overload release current setting: | 112 - 160 A |
Adjustment range undelayed short-circuit release: | 800 - 1600 A |
Power loss: | 28.2 W |
Device construction: | Built-in device fixed built-in technique |
Integrated earth fault protection: | no |
Type of electrical connection of main circuit: | Screw connection |
Suitable for DIN rail (top hat rail) mounting: | no |
DIN rail (top hat rail) mounting optional: | yes |
With switched-off indicator: | no |
With integrated under voltage release: | no |
Number of poles: | 2 |
Position of connection for main current circuit: | Front side |
Type of control element: | Rocker lever |
Complete device with protection unit: | yes |
Motor drive integrated: | no |
Motor drive optional: | yes |
Degree of protection (IP): | IP20 |
