Ex9NL-N 3P+N C16 300mA EU Wył. różn. z zabezp. nadpr., Icn=6kA, 3+Nbieg, char. C, In=16A, IΔn=300mA, type AC
Information | Value |
---|---|
Supplier | NOARK Electric Sp. z o.o. |
Symbol | 111522 |
GTIN(EAN) | 8592765115225 |
Price unit | piece |
Catalog price | 732,97 zł (595,91 zł + 23% VAT) |
Promotions related to this product
-
Are you reals ? !
Dokonaj zakupów produktów NOARK na kwotę powyżej 1500 zł brutto, a w prezencie otrzymasz Uchwyt Selfie marki VÖGEL BSF305K !
-
LETNIE ORZEŹWIENIE
Przy zakupach produktów NOARK w ElektRa Hurtownia Elektrotechniczna na kwotę 5000 zł brutto otrzymasz prezent Saturator Brita SodaOne
Additional features:
Information | Value |
---|---|
Net weight: | 422 g |
ETIM class: | Earth leakage circuit breaker |
Voltage type: | AC |
Built-in depth: | 77 mm |
Rated current: | 16 A |
Rated voltage: | 400 V |
Release characteristic: | C |
Rated insulation voltage Ui: | 500 V |
Rated fault current: | 0.3 A |
Leakage current type: | AC |
Surge current capacity: | 3 kA |
Current limiting class: | 3 |
Over voltage category: | 3 |
Pollution degree: | 2 |
Width in number of modular spacings: | 4 |
Power loss: | 8.4 W |
Frequency: | 50/60 Hz |
Degree of protection (IP): | IP20 |
Number of protected poles: | 3 |
Concurrently switching neutral conductor: | yes |
Number of poles (total): | 4 |
Anti-nuisance tripping version: | no |
Rated impulse withstand voltage Uimp: | 4 kV |
Order
Additional information:
Information | Value |
---|---|
Updated: | 2024-05-14 12:02:47 |
Files to download: | |
External links: |
