Ex9NLE EL 1PN C40 30mA A Elektroniczny wyłącznik różnicowoprądowy z zabezpieczeniem nadprądowym, 1 moduł szerokości, 1+Nbieg, char. C, In=40A, IΔn=30mA, typ A
Information | Value |
---|---|
Supplier | NOARK Electric Sp. z o.o. |
Symbol | 111173 |
GTIN(EAN) | 8592765111739 |
Price unit | piece |
Catalog price | 346,15 zł (281,42 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Promotions related to this product
-
Are you reals ? !
Dokonaj zakupów produktów NOARK na kwotę powyżej 1500 zł brutto, a w prezencie otrzymasz Uchwyt Selfie marki VÖGEL BSF305K !
-
LETNIE ORZEŹWIENIE
Przy zakupach produktów NOARK w ElektRa Hurtownia Elektrotechniczna na kwotę 5000 zł brutto otrzymasz prezent Saturator Brita SodaOne
Additional features:
Information | Value |
---|---|
Net weight: | 121 g |
ETIM class: | Earth leakage circuit breaker |
Voltage type: | AC |
Built-in depth: | 77 mm |
Rated current: | 40 A |
Rated voltage: | 230 V |
Release characteristic: | C |
Rated insulation voltage Ui: | 500 V |
Rated fault current: | 0.03 A |
Leakage current type: | A |
Surge current capacity: | 3 kA |
Current limiting class: | 3 |
Over voltage category: | 3 |
Pollution degree: | 2 |
Width in number of modular spacings: | 1 |
Power loss: | 9.13 W |
Frequency: | 50/60 Hz |
Degree of protection (IP): | IP20 |
Number of protected poles: | 1 |
Concurrently switching neutral conductor: | yes |
Number of poles (total): | 2 |
Anti-nuisance tripping version: | no |
Rated impulse withstand voltage Uimp: | 4 kV |
