Ex9BP-JX(+) 4P K63 Wył. nadpr. DC 10 kA, ch-ka K, 63 A, 1000 V DC, 4 moduły szer.
Information | Value |
---|---|
Supplier | NOARK Electric Sp. z o.o. |
Symbol | 110170 |
GTIN(EAN) | 8592765101709 |
Price unit | piece |
Catalog price | 202,62 zł (164,73 zł + 23% VAT) |
Promotions related to this product
-
Are you reals ? !
Dokonaj zakupów produktów NOARK na kwotę powyżej 1500 zł brutto, a w prezencie otrzymasz Uchwyt Selfie marki VÖGEL BSF305K !
-
LETNIE ORZEŹWIENIE
Przy zakupach produktów NOARK w ElektRa Hurtownia Elektrotechniczna na kwotę 5000 zł brutto otrzymasz prezent Saturator Brita SodaOne
Additional features:
Information | Value |
---|---|
Net weight: | 480 g |
ETIM class: | Miniature circuit breaker (MCB) |
Voltage type: | DC |
Built-in depth: | 74 mm |
Rated current: | 63 A |
Rated voltage: | 1000 V |
Release characteristic: | K |
Rated insulation voltage Ui: | 1000 V |
Current limiting class: | 3 |
Over voltage category: | 3 |
Pollution degree: | 3 |
Width in number of modular spacings: | 4 |
Explosion-proof: | no |
Power loss: | 17.6 W |
Degree of protection (IP): | IP20 |
Number of protected poles: | 4 |
Concurrently switching neutral conductor: | no |
Connectable conductor cross section solid-core: | 1 - 35 mm² |
Ambient temperature during operating: | -35 - 70 °C |
Flush-mounted installation: | no |
Additional equipment possible: | yes |
Number of poles (total): | 4 |
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V: | 10 kA |
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V: | 10 kA |
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V: | 10 kA |
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V: | 10 kA |
Rated impulse withstand voltage Uimp: | 4 kV |
