Ex9BP-JX(+) 1P C2 Wył. nadpr. DC 10 kA, ch-ka C, 2 A, 250 V DC, 1 moduł szer.
Information | Value |
---|---|
Supplier | NOARK Electric Sp. z o.o. |
Symbol | 110068 |
GTIN(EAN) | 8592765100689 |
Price unit | piece |
Catalog price | 141,39 zł (114,95 zł + 23% VAT) |
Promotions related to this product
-
Are you reals ? !
Dokonaj zakupów produktów NOARK na kwotę powyżej 1500 zł brutto, a w prezencie otrzymasz Uchwyt Selfie marki VÖGEL BSF305K !
-
LETNIE ORZEŹWIENIE
Przy zakupach produktów NOARK w ElektRa Hurtownia Elektrotechniczna na kwotę 5000 zł brutto otrzymasz prezent Saturator Brita SodaOne
Additional features:
Information | Value |
---|---|
Net weight: | 120 g |
ETIM class: | Miniature circuit breaker (MCB) |
Release characteristic: | C |
Number of poles (total): | 1 |
Number of protected poles: | 1 |
Rated current: | 2 A |
Rated voltage: | 250 V |
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V: | 10 kA |
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V: | 10 kA |
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V: | 10 kA |
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V: | 10 kA |
Voltage type: | DC |
Current limiting class: | 3 |
Concurrently switching neutral conductor: | no |
Over voltage category: | 3 |
Pollution degree: | 3 |
Width in number of modular spacings: | 1 |
Built-in depth: | 72 mm |
Additional equipment possible: | yes |
Degree of protection (IP): | IP20 |
Rated insulation voltage Ui: | 1000 V |
Rated impulse withstand voltage Uimp: | 4 kV |
Power loss: | 2 W |
Flush-mounted installation: | no |
Ambient temperature during operating: | -35 - 70 °C |
Connectable conductor cross section solid-core: | 1 - 35 mm² |
Explosion-proof: | no |
